NUX DA-50 electronic drum and keyboard special speaker

DA50 drum amp

The DA50 electronic drum monitor speaker is a special speaker for electronic drums. It can amplify the drum sound signal generated by the sound source with a power of 30W. It also has a CD/LINE input, which can mix audio or other sound source signals through this speaker.​​​ The amplified output can provide a good auxiliary practice method for drummers and practitioners, and the headphone output interface is convenient for monitoring.

The 10-inch full-range speaker, with a small tweeter, has obvious frequency response characteristics. The circuit design is optimized for the frequency characteristics of various drum instruments. The treble is bright, the midrange is full, and the bass is shocking.

It has three frequency adjustment buttons: treble, midrange, and bass, which provide better adjustability to meet the needs of different drummers and practitioners for drum sounds.

What is TSAC technology?

It is a new digital technique for simulating the operating characteristics of analog circuits. TSAC adds digital simulation algorithms to simulate the transient characteristics of analog circuits. In general, musicians will feel dissatisfied with professional-grade analog-designed simulated sound effects such as tube amps and distortion effects. Because of the lack of a certain feel and dynamics compared to real analog equipment, the application of TSAC technology improves both.

TSAC technology is mainly used in algorithms for nonlinear circuit simulation, including distortion, fuzz and overdrive effects in NUX effects and amps, and guitar amp simulations (pre-amp, post-amp) use this new technology. Thanks to modern powerful DSP computing power, our effects and amps can sound richer than other similar products, giving the musicians a "feel".

Rated power: 50W RMS

Power consumption: 40W 50/60HZ 230 VAC

input resistance

INPUT1: 68KΩ

INPUT2: 68KΩ

Input sensitivity

INPUT1: -36DB

INPUT2: -36DB

EQ equalization system

BASS: ±15DB @ 60HZ

TREBLE: +/-15DB@10KHZ

CD Input: -10DBV (2 X RCA)

Speaker: Coaxial speaker (10” WOOF + 1” TWEETER)

Size: 430(H)*390(W)*340(D)​​ MM

Net weight: 12KG

Gross weight: 14KG
