Roland FA-07 Music Workstation

Make music workstations more than just work

Roland's new FA series completely subverts your imagination of music workstations, making music work streamlined and smooth with its effortless immediacy, ultra-fast workflow, and the most versatile functionality. Each model in the series inherits a large selection of the flagship sound source, a variety of studio-grade effects, expressive real-time control, and a built-in sampler with zero load time, which can be used with 16 Press the key to play immediately. The arranger also features easy-to-use, uninterrupted loop recording, allowing you to capture inspiration immediately and export as multi-track data for use in your DAW. Series models include the 61- key FA-06 and the 76- key FA-07 are equipped with a velocity-sensitive keyboard, and the FA-08 is equipped with an 88- key keyboard with a gravity mechanism.

keyboard

keyboard

76 keys (with velocity-sensitive semi-weighted keyboard)

source area

Maximum number of simultaneous voices

128 voices (varies according to source load)

voice

16 voices

number of timbres

SuperNATURAL Acoustic

SuperNATURAL Synth

SuperNATURAL Drum Kit

PCM Synth

PCM Drum Kit

* Includes GM2 compatible tone.

Wave Expansion Slot

2 expansion slots

The * -shaped expansion slot is the rewritable internal waveform memory. You can download data from the Axial library website and write to the FA 's internal waveform memory (expansion slot) via a USB flash drive.

Favorite tone ( Favorite )

have

Effects

Multi-Effects: 16 systems, 68 types ( Vocoder is only available for Part 1 )

Part EQ: 16 systems

Drum Part COMP+EQ: 6 systems

Chorus: 3 types

Reverb: 6 types

Master Compressor (can be changed to Insert FX ( 78 types))

Master EQ Master Equalizer

Total Effects ( TFX ) : 29 types

Mic Input Reverb: 8 types

arranger

MIDI track

16

file format

Original , support SMF export / import, support WAV export

* Can record sampler-triggered data.

sampler

Format

16-bit linear , 44.1 kHz , support WAV/AIFF/MP3 import

Maximum number of simultaneous voices

8

Number of samples

16 key presses x 4 Banks (for each song)

* Sampling cannot be used as waveform data for a tone generator.

other

rhythm section

have

Arpeggiator

have

Chord Memory (Chord Memory)

have

control device

D-BEAM Controller

Pitch Bend/Modulation joystick

Customizable function switch x 2 ( S1/S2 )

Control knob x 6

Sampling button

speed knob

display

5 -inch graphic color LCD

external memory

SD card (support SDHC )

connection terminal

Headphone jack : Stereo 1/4 inch headphone type

MAIN output jacks ( L/MONO , R ) : 1/4 inch TRS phone type

Sub Output jack : Stereo 1/4 inch phone type

AUDIO INPUT jack

LINE: Stereo miniature phone type

GUITAR/MIC: 1/4 inch phone type

FOOT PEDAL contacts ( CTRL 1 , CTRL 2 , HOLD )

MIDI connection terminals ( IN , OUT )

USB FOR UPDATE port

USB COMPUTER port ( USB Hi-Speed AUDIO/MIDI )

(Use a USB cable with a USB 2.0 Hi-Speed capable USB port on your computer)

DC IN jack

power supply

AC Transformer

current

1 , 300 mA

Appendix

Quick start

Document "USING THE UNIT SAFELY"

SD card (installed on this unit at the factory)

SD card protective cover (installed on this unit at the factory)

AC Transformer

power cable

Optional equipment

Keyboard stand( *1 ) : KS-18Z , KS-12

Switch pedal : DP series

Expression Pedal : EV-5

USB flash drive ( *2 )

Wireless LAN USB Adapter : WNA1100-RL

*1 When using the KS-18Z , be sure to confirm that the height of the unit is one meter or less.

*2 We cannot guarantee that all commercially available USB flash drives will work properly with this unit.

size and weight

width

1 , 231 mm

48-1/2 inches

deep

311 mm

12-1/4 inches

high

107mm

4-1/4 inches

weight

8.5kg

18 lbs. 12 oz.
